G-2170 Grommet Shackle

Details of the Crosby G-2170 Grommet Shackle:

• All sizes Quenched and Tempered for maximum strength;
• All sizes cast alloy steel;
• All ratings are in metric tons, embossed on side of bow;
• G-2170 bows are furnished Dimetcoted and pins are Dimetcoted, then painted red;
• All sizes are RFID EQUIPPED in bow and pin;
• Designed for use with single or double large diameter grommets;
• Extra large sling contact area improves efficiency of the grommet sling;
• Shackles utilize new Easy-Loc bolt system;
• Large machined flat on ears that can be drilled and tapped for adapting other accessories;
• Increases usable sling strength minimum of 60% and greatly improves life of grommet slings;
• Bow and bolt are certified to meet charpy impact testing of 42 joules (31 ft-lbs.) min. avg. at -20 degrees C (-4 degrees F);
• All 2170 shackles are individually proof tested and magnetic particle inspected;
• Shackles requiring ABS, Lloyds, and other certifications are available upon special request and must be specified at time of order;
• All 2170 shackles can meet requirements of DNV Rules for Certification of Lifting Appliances upon special request and must be specified at time of order;
• Serialization / Identification;
• Material Testing (Physical / Chemical / Charpy);
• Proof Testing;
• Look for the Red Pin®….the mark of genuine Crosby quality.

*NOTE:
WLL ≤ 25 ton           → PL = 2 · g · WLL                kN
WLL > 25 ≤ 180 ton → PL = 1,22 · g · WLL + 200 kN
WLL > 180 ton         → PL = 1,33 · g · WLL           kN
