The Hi-Force MHP Range of manually operated two speed hydraulic pumps are suitable for use with a wide variety of
fluids including water. Manufactured predominantly from high quality aluminium alloy, with stainless steel piston
assemblies, the MHP pump series are lightweight, versatile and robust. The pumps two stage piston design gives a
high flow low pressure stage of 50cm3 up to 50 Bar pressure. The pump incorporates a reliable smooth manual
changeover from low to high pressure output. The MHP series pumps are available in 5 different pressure capacities
ranging from 100 to 1000 Bar working pressure and all models are fitted with a factory pre-set relief valve for added
safety. Each pump is supplied with a multi positional 610mm operating lever for increased operator comfort during
use. Major applications for the MHP series of pumps include hydro-testing of pipes, pressure vessels, valves, and also
back-up systems and other pressure retaining equipment, prior to commissioning.
| MODEL NUMBER (WITH TANK) | MODEL NUMBER PUMP ONLY | WORKING PRESSURE BAR | VALVE TYPE | DISPLACEMENT PER STROKE CM3 | CHANGEOVER PRESSURE BAR | OUTLET PORT | SUCTION PORT | WEIGHT WITH TANK KG | |
|---|---|---|---|---|---|---|---|---|---|
| 1STSTAGE | 2NDSTAGE | ||||||||
| MHP100 | MHP100PU | 100 | 2-way | 50 | 22 | 50 | 3/8″ NPT | 3/8″ BSP | 20 |
| MHP300 | MHP300PU | 300 | 2-way | 50 | 8 | 50 | 3/8″ NPT | 3/8″ BSP | 20 |
| MHP500 | MHP500PU | 500 | 2-way | 50 | 4 | 50 | 3/8″ NPT | 3/8″ BSP | 20 |
| MHP700 | MHP700PU | 700 | 2-way | 50 | 3 | 50 | 3/8″ NPT | 3/8″ BSP | 20 |
| MHP1000 | MHP1000PU | 1000 | 2-way | 50 | 2 | 50 | 3/8″ BSP | 3/8″ BSP | 20 |
