Compression Tool P-5368 for ROV spring release shackles
• Material : mild steel
• Finish : black painted
• Note : required for ROV spring release shackle (type P-5367), for sizes WLL 42.5 t and up.
| For Shackle WLL | Diameter Bow | Diameter Pin | Width | Length Closed Position | Length Opened Posistion | Height | Width | Weight Each | |
| t | A mm | B mm | A mm | B mm | C mm | D mm | E mm | kg | |
| 42.5 | 57 | 65 | 300 | 1000 | 1500 | 225 | 24 | 34 | |
| 55 | 65 | 70 | |||||||
| 85 | 75 | 83 | |||||||
| 120 | 95 | 95 | 340 | 1100 | 1750 | 285 | 24 | 42 | |
| 150 | 105 | 108 |
